EUROSAFE PORTABLE INLINE FOAM INDUCTOR
DESCRIPTION
The foam liquid concentrate is inducted into the water stream by an inline foam inductor, which supplies a proportional solution of the liquid concentrate and water to the foam production equipment. The inductors are primarily intended for use in fixed foam installations, where they provide a simple and dependable means of proportioning in continuous flow applications.
The inductor is built for a certain water pressure and discharge rate to provide accurate proportioning. Increases or decreases in inlet pressure cause a rise or reduction in flow rate, which in turn changes the proportioning.
FEATURES
- Main Material: Aluminum Alloy and brass;
- Working Pressure: 0.7-1.0MPa;
- Surface Finishing: Fire Red Painting;
- Coupling : STORZ, John Morris, GOST, Machino, etc.
- NFPA Compliance
TECHNICAL PARAMETER
| Model Number | ES0307-A |
| Working Pressure | 0.7-1.0MPa |
| Flow Rate | 240 LPM @ 0.7MPa 360 LPM@ 1.0MPa |
| Connecting Size | 2.5” |
| Foam Solution Ratio | 1% – 6% (adjustable) |
